Name: 12-3/4 Inch 304L Stainless Steel Wire Wrapped Screen for Sand Control
Brand: Anping County Hengyuan Hardware Netting Industry Product Co.,Ltd.
SKU: 12-3/4"
Price: 105.00 USD
Availability: InStock

Rumah > Produk > Layar Dibungkus Kawat >

12-3/4 Inch 304L Stainless Steel Wire Wrapped Screen for Sand Control

304L stainless steel wire wrapped screen

sand control wire wrapped screen

12-3/4 inch wire wrapped screen

Tempat asal:

Hengshui, Hebei, Tiongkok

Nama merek:

Heng Yuan

Sertifikasi:

ISO9000

Nomor model:

12-3/4"

Hubungi kami

Permintaan Penawaran

Rincian Produk

Nama:

Layar terbungkus kawat

Bahan:

Baja Tahan Karat 304L

Diameter:

325mm

Panjang:

5800mm

Ukuran celah:

0,75 mm

Bungkus kawat:

3.0 × 5.0mm

Batang penyangga:

ø4.0mm

TIDAK. batang:

59nos

Akhiri Koneksi:

Pria / wanita berulir

Berat badan:

160kg/potong

Paket:

film plastik

Penggunaan:

Di sumur air untuk kontrol pasir

Produk-produk terkait

video

25 - 1027 mm Diameter Layar Dibungkus Kawat Sumur Air Untuk Filter Pasir

Dapatkan Harga Terbaik

video

Stainless Stelel 304 Water Well Wedge Wire Screen Diameter 89mm

Dapatkan Harga Terbaik

video

Mudah Membersihkan Pipa Layar Sumur Air / Wire Wrap Mesh Multi Fungsi

Dapatkan Harga Terbaik

video

Layar Drum Cuci Kembali Otomatis, OD 600 MM Wire Wrap Screen Mesh

Dapatkan Harga Terbaik

Hubungi kami

86-318-7565918

hengyuan1@aphywire.com

86-318-7565919

Hubungi sekarang

Deskripsi Produk

12-3/4" Stainless Steel 304L Wire Wrapped Screen For Sand Control

Product Specifications

Attribute	Value
Name	Wire Wrapped Screen
Material	Stainless steel 304L
Diameter	325mm
Length	5800mm
Slot size	0.75 mm
Wrap wire	3.0×5.0mm
Support rod	ø4.0mm
NO. of rod	59NOS
End connection	Male/female threaded
Weight	160KG/piece
Package	Plastic film
Use	In water wells for sand control

Product Description

Hengyuan Wire Wrapped Screens are a versatile, cost-effective sand control solution for various well environments. These screens provide optimal balance between effective sand control and long-term well productivity at an affordable price point.

Key Features

Fully customizable for specific well applications
Strong assemblies resistant to erosion
Prevents plugging by fines or produced solids
Exclusive slip-ring design isolates wire-wrap jacket from mechanical loads
Maintains efficient sand control under compression, tension, or torque

Standard Specifications

Materials: Stainless steel 202, 304, 304L, 316L, Non-magnetic Stainless steel, Low carbon galvanized
Diameter Range: 3" to 18"
Slot Sizes: 0.1-100mm (Standard: 0.5mm, 0.63mm, 0.75mm, 1.0mm, 1.5mm)
Length Options: 100-6000mm (Standard: 2.9m/3m and 5.8m/6m for container shipping)

Technical Support

Sand analysis of formation materials
Screen size recommendations
Screen installation suggestions
Well construction consultation

Our technical team includes expert design engineers, welders, and support personnel with comprehensive knowledge of downhole screen manufacturing and deployment for diverse applications.
